PA-RI 20/1 Stainless steel reinforced hose clamp
Wide, strong one-piece hose clamp
Technical specifications:

The reinforced clamp consists of a wide steel strong band and bolt.

The stainless steel band is 20 mm wide and 1 mm thick with an M 6 x 45 Allen bolt.


hose clamp - stainless steel clamp - one piece clamp - reinforced hose clamp

The product is a permanent storage lots. Meantime, we hold the right of selling the stock in products.

Range
of dimensions (mm)		 Nominal
size		 Article
number		 Quote
request for the entire size scale
28 - 34 33 6170 025031 Request a quote
30 - 36 35 6170 030036 Request a quote
35 - 41 40 6170 035041 Request a quote
40 - 46 45 6170 040046 Request a quote
45 - 51 50 6170 045051 Request a quote
50 - 56 55 6170 050056 Request a quote
55 - 61 60 6170 055061 Request a quote
60 - 66 65 6170 060066 Request a quote
65 - 72 70 6170 065072 Request a quote
70 - 77 75 6170 070077 Request a quote
75 - 82 80 6170 075082 Request a quote
80 - 87 85 6170 080087 Request a quote
85 - 92 90 6170 085092 Request a quote
90 - 97 95 6170 090097 Request a quote
95 - 102 100 6170 095102 Request a quote
105 - 112 110 6170 105112 Request a quote
115 - 122 120 6170 115122 Request a quote
125 - 132 130 6170 125132 Request a quote
130 - 137 135 6170 130137 Request a quote
135 - 142 140 6170 135142 Request a quote
142 - 152 150 6170 145152 Request a quote
155 - 162 160 6170 155162 Request a quote
165 - 172 170 6170 165172 Request a quote
175 - 182 180 6170 175182 Request a quote
185 - 192 190 6170 185192 Request a quote
195 - 203 200 6170 195203 Request a quote
